Categories	Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Datasheet	GBPC15005-G thru GBPC5010-G
Standard Package	50
Manufacturer	Comchip Technology
Series	-
Packaging	Bulk
Part Status	Active
Diode Type	Single Phase
Technology	Standard
Voltage - Peak Reverse (Max)	800V
Current - Average Rectified (Io)	35A
Voltage - Forward (Vf) (Max) @ If	1.1V @ 17.5A
Current - Reverse Leakage @ Vr	5µA @ 800V
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	QC Terminal
Package / Case	4-Square, GBPC
Supplier Device Package	GBPC
Base Part Number	GBPC3508
