HPL1005-4N7

Part NumberHPL1005-4N7

ManufacturerSusumu

DescriptionFIXED IND 4.7NH 500MA 500 MOHM

DatasheetHPL Series Datasheet

Package / Case0402 (1005 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description4.7nH Unshielded Thin Film Inductor 500mA 500mOhm Max 0402 (1005 Metric)

To learn about the specification of HPL1005-4N7, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add HPL1005-4N7 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of HPL1005-4N7.
We are offering HPL1005-4N7 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

HPL1005-4N7 - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

HPL Series Datasheet

Standard Package

10000

Manufacturer

Susumu

Series

HPL

Packaging

Tape & Reel (TR)

Part Status

Obsolete

Type

Thin Film

Material - Core

Inductance

4.7nH

Tolerance

±0.2nH

Current Rating (Amps)

500mA

Current - Saturation

Shielding

Unshielded

DC Resistance (DCR)

500mOhm Max

Q @ Freq

13 @ 300MHz

Frequency - Self Resonant

6GHz

Ratings

Operating Temperature

Inductance Frequency - Test

300MHz

Mounting Type

Surface Mount

Package / Case

0402 (1005 Metric)

Supplier Device Package

0402 (1005 Metric)

Size / Dimension

0.039" L x 0.020" W (1.00mm x 0.50mm)

Height - Seated (Max)

0.013" (0.33mm)
