IPW60R090CFD7XKSA1

IPW60R090CFD7XKSA1

Part NumberIPW60R090CFD7XKSA1

ManufacturerInfineon Technologies

DescriptionHIGH POWER_NEW

Datasheet600 V CoolMOS? CFD7 SJ MOSFET Brief

Package / CaseTO-247-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 600V 25A (Tc) 125W (Tc) Through Hole PG-TO247-3

To learn about the specification of IPW60R090CFD7XKSA1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IPW60R090CFD7XKSA1 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IPW60R090CFD7XKSA1.
We are offering IPW60R090CFD7XKSA1 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IPW60R090CFD7XKSA1 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	600 V CoolMOS? CFD7 SJ MOSFET Brief
Standard Package	240
Manufacturer	Infineon Technologies
Series	OptiMOS™
Packaging	Tube
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	600V
Current - Continuous Drain (Id) @ 25°C	25A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	90mOhm @ 11.4A, 10V
Vgs(th) (Max) @ Id	4.5V @ 570µA
Gate Charge (Qg) (Max) @ Vgs	51nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	2103pF @ 400V
FET Feature	-
Power Dissipation (Max)	125W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	PG-TO247-3
Package / Case	TO-247-3
