IRFU13N20DPBF

IRFU13N20DPBF

Part NumberIRFU13N20DPBF

ManufacturerInfineon Technologies

DescriptionMOSFET N-CH 200V 13A I-PAK

DatasheetIRF(R,U)13N20DPbF

Package / CaseTO-251-3 Short Leads, IPak, TO-251AA

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 200V 13A (Tc) 110W (Tc) Through Hole IPAK (TO-251)

To learn about the specification of IRFU13N20DPBF, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IRFU13N20DPBF with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IRFU13N20DPBF.
We are offering IRFU13N20DPBF for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IRFU13N20DPBF - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	IRF(R,U)13N20DPbF
Standard Package	3000
Manufacturer	Infineon Technologies
Series	HEXFET®
Packaging	Tube
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	200V
Current - Continuous Drain (Id) @ 25°C	13A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	235mOhm @ 8A, 10V
Vgs(th) (Max) @ Id	5.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	38nC @ 10V
Vgs (Max)	±30V
Input Capacitance (Ciss) (Max) @ Vds	830pF @ 25V
FET Feature	-
Power Dissipation (Max)	110W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	IPAK (TO-251)
Package / Case	TO-251-3 Short Leads, IPak, TO-251AA
