IXDH20N120

Part NumberIXDH20N120

ManufacturerIXYS

DescriptionIGBT 1200V 38A 200W TO247AD

DatasheetIXDH20N120(D1)

Package / CaseTO-3P-3 Full Pack

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionIGBT NPT 1200V 38A 200W Through Hole TO-247AD

To learn about the specification of IXDH20N120, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IXDH20N120 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IXDH20N120.
We are offering IXDH20N120 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IXDH20N120 - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - IGBTs - Single

Datasheet

IXDH20N120(D1)

Standard Package

Manufacturer

IXYS

Series

Packaging

Tube

Part Status

Active

IGBT Type

NPT

Voltage - Collector Emitter Breakdown (Max)

1200V

Current - Collector (Ic) (Max)

38A

Current - Collector Pulsed (Icm)

50A

Vce(on) (Max) @ Vge, Ic

3V @ 15V, 20A

Power - Max

200W

Switching Energy

3.1mJ (on), 2.4mJ (off)

Input Type

Standard

Gate Charge

70nC

Td (on/off) @ 25°C

Test Condition

600V, 20A, 82Ohm, 15V

Operating Temperature

-55°C ~ 150°C (TJ)

Mounting Type

Through Hole

Package / Case

TO-3P-3 Full Pack

Supplier Device Package

TO-247AD

Base Part Number

IXD*20N120
