IXYP10N65C3D1

Part NumberIXYP10N65C3D1

ManufacturerIXYS

DescriptionIGBT 650V 30A 160W TO-220

DatasheetIXYP10N65C3D1 Datasheet

Package / CaseTO-220-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionIGBT PT 650V 30A 160W Through Hole TO-220

To learn about the specification of IXYP10N65C3D1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IXYP10N65C3D1 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IXYP10N65C3D1.
We are offering IXYP10N65C3D1 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IXYP10N65C3D1 - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - IGBTs - Single

Datasheet

IXYP10N65C3D1 Datasheet

Standard Package

Manufacturer

IXYS

Series

GenX3™, XPT™

Packaging

Tube

Part Status

Active

IGBT Type

Voltage - Collector Emitter Breakdown (Max)

650V

Current - Collector (Ic) (Max)

30A

Current - Collector Pulsed (Icm)

54A

Vce(on) (Max) @ Vge, Ic

2.5V @ 15V, 10A

Power - Max

160W

Switching Energy

240µJ (on), 110µJ (off)

Input Type

Standard

Gate Charge

18nC

Td (on/off) @ 25°C

20ns/77ns

Test Condition

400V, 10A, 50Ohm, 15V

Reverse Recovery Time (trr)

170ns

Operating Temperature

-55°C ~ 175°C (TJ)

Mounting Type

Through Hole

Package / Case

TO-220-3

Supplier Device Package

TO-220
