Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	1N36xx,1N3957
Standard Package	1
Manufacturer	Microsemi Corporation
Series	Military, MIL-PRF-19500/228
Packaging	Bulk
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	600V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	1.1V @ 1A
Speed	Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	100µA @ 300V
Capacitance @ Vr, F	-
Mounting Type	Through Hole
Package / Case	A, Axial
Operating Temperature - Junction	-65°C ~ 175°C

1SS196(TE85L,F)	Toshiba Semiconductor and Storage, Diode Standard 80V 100mA Surface Mount SC-59-3,	View
US1J R3G	Taiwan Semiconductor Corporation, Diode Standard 600V 1A Surface Mount DO-214AC (SMA),	View
S5D-E3/57T	Vishay Semiconductor Diodes Division, Diode Standard 200V 5A Surface Mount DO-214AB (SMC),	View
MUR460S R7G	Taiwan Semiconductor Corporation, Diode Standard 600V 4A Surface Mount DO-214AB (SMC),	View
STTH15L06G-TR	STMicroelectronics, Diode Standard 600V 20A Surface Mount D2PAK,	View
S3B-13-F	Diodes Incorporated, Diode Standard 100V 3A Surface Mount SMC,	View
UF4001-E3/54	Vishay Semiconductor Diodes Division, Diode Standard 50V 1A Through Hole DO-204AL (DO-41),	View
BYM10-600-E3/97	Vishay Semiconductor Diodes Division, Diode Standard 600V 1A Surface Mount DO-213AB, SUPERECTIFIER®	View
RFNL5BM6STL	Rohm Semiconductor, Diode Standard 600V 5A Surface Mount TO-252,	View
NSD914F3T5G	ON Semiconductor, Diode Standard 100V 200mA (DC) Surface Mount SOT-1123,	View
BAS19LT1G	ON Semiconductor, Diode Standard 120V 200mA (DC) Surface Mount SOT-23-3 (TO-236),	View
MUR420S V7G	Taiwan Semiconductor Corporation, Diode Standard 200V 4A Surface Mount DO-214AB (SMC),	View

JAN1N3613
