JAN1N5822

Part NumberJAN1N5822

ManufacturerMicrosemi Corporation

DescriptionDIODE SCHOTTKY 40V 3A AXIAL

Datasheet1N5820-22,1N6864

Package / CaseB, Axial

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Schottky 40V 3A Through Hole

To learn about the specification of JAN1N5822, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add JAN1N5822 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of JAN1N5822.
We are offering JAN1N5822 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

JAN1N5822 - Product Attributes

Categories

Discrete Semiconductor Products / Diodes - Rectifiers - Single

Datasheet

1N5820-22,1N6864

Standard Package

Manufacturer

Microsemi Corporation

Series

Military, MIL-PRF-19500/620

Packaging

Bulk

Part Status

Active

Diode Type

Schottky

Voltage - DC Reverse (Vr) (Max)

40V

Current - Average Rectified (Io)

Voltage - Forward (Vf) (Max) @ If

500mV @ 3A

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Current - Reverse Leakage @ Vr

100µA @ 40V

Capacitance @ Vr, F

Mounting Type

Through Hole

Package / Case

B, Axial

Supplier Device Package

Operating Temperature - Junction

-65°C ~ 125°C
