JANTXV2N3767

Part NumberJANTXV2N3767

ManufacturerM/A-Com Technology Solutions

DescriptionTRANS NPN 80V 4A TO-66

Datasheet2N3766,37~

Package / CaseTO-213AA, TO-66-2

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 80V 4A 25W Through Hole TO-66

To learn about the specification of JANTXV2N3767, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add JANTXV2N3767 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of JANTXV2N3767.
We are offering JANTXV2N3767 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

JANTXV2N3767 - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single

Datasheet

2N3766,37~

Standard Package

Manufacturer

M/A-Com Technology Solutions

Series

Military, MIL-PRF-19500/518

Packaging

Bulk

Part Status

Discontinued at Digi-Key

Transistor Type

NPN

Current - Collector (Ic) (Max)

Voltage - Collector Emitter Breakdown (Max)

80V

Vce Saturation (Max) @ Ib, Ic

2.5V @ 100mA, 1A

Current - Collector Cutoff (Max)

500µA

DC Current Gain (hFE) (Min) @ Ic, Vce

40 @ 500mA, 5V

Power - Max

25W

Frequency - Transition

Operating Temperature

-65°C ~ 200°C (TJ)

Mounting Type

Through Hole

Package / Case

TO-213AA, TO-66-2

Supplier Device Package

TO-66
