LGJ7045TS-4R7M2R1-H

Part NumberLGJ7045TS-4R7M2R1-H

ManufacturerTDK Corporation

DescriptionFIXED IND 4.7UH 2.1A 31 MOHM SMD

DatasheetLGJ7045TS-H Series Brief

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description4.7µH Shielded Wirewound Inductor 2.1A 31mOhm Nonstandard

To learn about the specification of LGJ7045TS-4R7M2R1-H, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LGJ7045TS-4R7M2R1-H with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LGJ7045TS-4R7M2R1-H.
We are offering LGJ7045TS-4R7M2R1-H for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

LGJ7045TS-4R7M2R1-H - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

LGJ7045TS-H Series Brief

Standard Package

1000

Manufacturer

TDK Corporation

Series

LGJ

Packaging

Tape & Reel (TR)

Part Status

Active

Type

Wirewound

Material - Core

Ferrite

Inductance

4.7µH

Tolerance

±20%

Current Rating (Amps)

2.1A

Current - Saturation

2.1A

Shielding

Shielded

DC Resistance (DCR)

31mOhm

Q @ Freq

Frequency - Self Resonant

Ratings

AEC-Q200

Operating Temperature

-40°C ~ 125°C

Inductance Frequency - Test

100kHz

Mounting Type

Surface Mount

Package / Case

Nonstandard

Size / Dimension

0.276" L x 0.276" W (7.00mm x 7.00mm)

Height - Seated (Max)

0.189" (4.80mm)
