LQM18PZ2R2MCHD

Part NumberLQM18PZ2R2MCHD

ManufacturerMurata Electronics North America

DescriptionFIXED IND 2.2UH 750MA 480 MOHM

DatasheetLQM18PZyyyyCHD Series Spec

Package / Case0603 (1608 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description2.2µH Shielded Multilayer Inductor 750mA 480mOhm Max 0603 (1608 Metric)

To learn about the specification of LQM18PZ2R2MCHD, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LQM18PZ2R2MCHD with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LQM18PZ2R2MCHD.
We are offering LQM18PZ2R2MCHD for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

LQM18PZ2R2MCHD - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	LQM18PZyyyyCHD Series Spec
Standard Package	1
Manufacturer	Murata Electronics North America
Series	LQM18
Packaging	Cut Tape (CT)
Part Status	Active
Type	Multilayer
Material - Core	Ferrite
Inductance	2.2µH
Tolerance	±20%
Current Rating (Amps)	750mA
Current - Saturation	200mA
Shielding	Shielded
DC Resistance (DCR)	480mOhm Max
Frequency - Self Resonant	50MHz
Ratings	AEC-Q200
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	1MHz
Mounting Type	Surface Mount
Package / Case	0603 (1608 Metric)
Supplier Device Package	0603 (1608 Metric)
Size / Dimension	0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max)	0.026" (0.65mm)
