LQP03TN18NJ04D

Part NumberLQP03TN18NJ04D

ManufacturerMurata Electronics North America

DescriptionFIXED IND 18NH 80MA 1.6 OHM SMD

DatasheetLQP03T_04 Series (0201 Size)

Package / Case0201 (0603 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description18nH Unshielded Thin Film Inductor 80mA 1.6Ohm Max 0201 (0603 Metric)

To learn about the specification of LQP03TN18NJ04D, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LQP03TN18NJ04D with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LQP03TN18NJ04D.
We are offering LQP03TN18NJ04D for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

LQP03TN18NJ04D - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

LQP03T_04 Series (0201 Size)

Standard Package

Manufacturer

Murata Electronics North America

Series

LQP03

Packaging

Cut Tape (CT)

Part Status

Obsolete

Type

Thin Film

Material - Core

Inductance

18nH

Tolerance

±5%

Current Rating (Amps)

80mA

Current - Saturation

Shielding

Unshielded

DC Resistance (DCR)

1.6Ohm Max

Q @ Freq

11 @ 500MHz

Frequency - Self Resonant

3.1GHz

Ratings

Operating Temperature

-40°C ~ 85°C

Inductance Frequency - Test

500MHz

Mounting Type

Surface Mount

Package / Case

0201 (0603 Metric)

Supplier Device Package

0201 (0603 Metric)

Size / Dimension

0.024" L x 0.012" W (0.60mm x 0.30mm)

Height - Seated (Max)

0.012" (0.31mm)
