LQW15AN17NG8ZD

Part NumberLQW15AN17NG8ZD

ManufacturerMurata Electronics North America

DescriptionFIXED IND 17NH 1A 126 MOHM

DatasheetLQW15ANyyyy8ZD Series Spec

Package / Case0402 (1005 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description17nH Unshielded Wirewound Inductor 1A 126mOhm Max 0402 (1005 Metric)

To learn about the specification of LQW15AN17NG8ZD, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LQW15AN17NG8ZD with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LQW15AN17NG8ZD.
We are offering LQW15AN17NG8ZD for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

LQW15AN17NG8ZD - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	LQW15ANyyyy8ZD Series Spec
Standard Package	1
Manufacturer	Murata Electronics North America
Series	LQW15
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Non-Magnetic
Inductance	17nH
Tolerance	±2%
Current Rating (Amps)	1A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	126mOhm Max
Q @ Freq	30 @ 250MHz
Frequency - Self Resonant	5GHz
Ratings	AEC-Q200
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	100MHz
Mounting Type	Surface Mount
Package / Case	0402 (1005 Metric)
Supplier Device Package	0402 (1005 Metric)
Size / Dimension	0.039" L x 0.024" W (1.00mm x 0.60mm)
Height - Seated (Max)	0.024" (0.60mm)
