Categories	Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Datasheet	MA46H120 Series
Standard Package	100
Manufacturer	M/A-Com Technology Solutions
Series	-
Packaging	Bulk
Part Status	Active
Capacitance @ Vr, F	0.2pF @ 10V, 1MHz
Capacitance Ratio Condition	-
Voltage - Peak Reverse (Max)	20V
Diode Type	Single
Q @ Vr, F	3000 @ 4V, 50MHz
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	2-SMD
Supplier Device Package	-

SMVA1705-004LF	Skyworks Solutions Inc., Varactor 1 Pair Common Cathode 12V Surface Mount SOT-23,	View
1SV239TPH3F	Toshiba Semiconductor and Storage, Varactor Single 15V Surface Mount USC,	View
SMV1405-079LF	Skyworks Solutions Inc., Varactor Single 30V Surface Mount SC-79,	View
BB639E7904HTSA1	Infineon Technologies, Varactor Single 30V Surface Mount PG-SOD323-2,	View
1SV280,H3F	Toshiba Semiconductor and Storage, Varactor Single 15V Surface Mount ESC,	View
SMV1245-079LF	Skyworks Solutions Inc., Varactor Single 26V Surface Mount SC-79,	View
BB208-02,115	NXP USA Inc., Varactor Single 10V Surface Mount SOD-523,	View
SMV1249-079LF	Skyworks Solutions Inc., Varactor Single 15V Surface Mount SC-79,	View
MA46H203-1056	M/A-Com Technology Solutions, Varactor Single 22V Surface Mount,	View
SMV1233-079LF	Skyworks Solutions Inc., Varactor Single 15V Surface Mount SC-79,	View
BBY6502VH6327XTSA1	Infineon Technologies, Varactor Single 15V Surface Mount PG-SC79-2,	View
SMV1276-079LF	Skyworks Solutions Inc., Varactor Single 10V Surface Mount SC-79,	View

MA46H120

Part NumberMA46H120
