MJD44H11-1G

MJD44H11-1G

Part NumberMJD44H11-1G

ManufacturerON Semiconductor

DescriptionTRANS NPN 80V 8A IPAK

DatasheetMJD44H11, MJD45H11

Package / CaseTO-251-3 Short Leads, IPak, TO-251AA

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 80V 8A 85MHz 1.75W Through Hole I-PAK

To learn about the specification of MJD44H11-1G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add MJD44H11-1G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of MJD44H11-1G.
We are offering MJD44H11-1G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

MJD44H11-1G - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	MJD44H11, MJD45H11
Standard Package	75
Manufacturer	ON Semiconductor
Series	-
Packaging	Tube
Part Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	8A
Voltage - Collector Emitter Breakdown (Max)	80V
Vce Saturation (Max) @ Ib, Ic	1V @ 400mA, 8A
Current - Collector Cutoff (Max)	1µA
DC Current Gain (hFE) (Min) @ Ic, Vce	40 @ 4A, 1V
Power - Max	1.75W
Frequency - Transition	85MHz
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-251-3 Short Leads, IPak, TO-251AA
Supplier Device Package	I-PAK
Base Part Number	MJD44H11
