Categories	Capacitors / Film Capacitors
Datasheet	WIMA MKP 10
Standard Package	3000
Manufacturer	WIMA
Series	-
Packaging	Bulk
Part Status	Active
Capacitance	0.033µF
Tolerance	±20%
Voltage Rating - AC	250V
Voltage Rating - DC	400V
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.512" L x 0.197" W (13.00mm x 5.00mm)
Height - Seated (Max)	0.433" (11.00mm)
Termination	PC Pins
Lead Spacing	0.394" (10.00mm)
Applications	High Pulse, DV/DT
Ratings	-
Features	-

MKP1G016802C00KSSD	WIMA, 6800pF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
MKP1F034704J00KSSD	WIMA, 0.47µF Film Capacitor 180V 250V Polypropylene (PP), Metallized Radial,	View
MKP1U012204B00JSSD	WIMA, 2200pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1F042206F00KSSD	WIMA, 2.2µF Film Capacitor 180V 250V Polypropylene (PP), Metallized Radial,	View
MKP1J024705B00JSC9	WIMA, 0.047µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial,	View
MKP1U014705B00JSSD	WIMA, 4700pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1T026806A00KSSD	WIMA, 0.068µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
MKP1G031504F00MSSD	WIMA, 0.15µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
MKP1U031006D00KSSD	WIMA, 0.1µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1U021005B00JSSD	WIMA, 10000pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1U022205D00KSSD	WIMA, 0.022µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1U011503C00MSSD	WIMA, 1500pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View

MKP1G023303F00MSSD

Part NumberMKP1G023303F00MSSD
