Categories	Capacitors / Film Capacitors
Datasheet	WIMA MKP 10
Standard Package	1000
Manufacturer	WIMA
Series	-
Packaging	Bulk
Part Status	Active
Capacitance	4700pF
Tolerance	±5%
Voltage Rating - AC	700V
Voltage Rating - DC	2000V (2kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.043" L x 0.236" W (26.50mm x 6.00mm)
Height - Seated (Max)	0.591" (15.00mm)
Termination	PC Pins
Lead Spacing	0.886" (22.50mm)
Applications	High Pulse, DV/DT
Ratings	-
Features	-

MKP1U031506F00KSSD	WIMA, 0.15µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1T026806A00KSSD	WIMA, 0.068µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
MKP1V014704C00JSSD	WIMA, 4700pF Film Capacitor 700V 2500V (2.5kV) Polypropylene (PP), Metallized Radial,	View
MKP1J031005D00JSSD	WIMA, 0.1µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial,	View
MKP1G043307G00KSSD	WIMA, 3.3µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
MKP1T023304F00KSSD	WIMA, 0.033µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
MKP1J026805B00KSSD	WIMA, 0.068µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial,	View
MKP1U023305F00JSSD	WIMA, 0.033µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
MKP1O133306F00KSSD	WIMA, 0.33µF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial,	View
MKP1V021005F00KSSD	WIMA, 10000pF Film Capacitor 700V 2500V (2.5kV) Polypropylene (PP), Metallized Radial,	View
MKP1O123304D00JSC9	WIMA, 0.033µF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial,	View
MKP1T024706A00KSSD	WIMA, 0.047µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View

MKP1U014705B00JSSD

Part NumberMKP1U014705B00JSSD
