Categories	Discrete Semiconductor Products / Diodes - Zener - Single
Datasheet	MMSZ5221B - MMSZ5267B,C
Standard Package	3000
Manufacturer	Micro Commercial Co
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Voltage - Zener (Nom) (Vz)	12V
Tolerance	±5%
Power - Max	500mW
Impedance (Max) (Zzt)	30 Ohms
Current - Reverse Leakage @ Vr	1µA @ 9.1V
Voltage - Forward (Vf) (Max) @ If	900mV @ 10mA
Operating Temperature	-55°C ~ 150°C
Mounting Type	Surface Mount
Package / Case	SOD-123
Supplier Device Package	SOD-123
Base Part Number	MMSZ5242B

MMSZ4701-TP	Micro Commercial Co, Zener Diode 14V 500mW ±5% Surface Mount SOD-123,	View
MMSZ5221B-TP	Micro Commercial Co, Zener Diode 2.4V 500mW ±5% Surface Mount SOD-123,	View
MMSZ5258B-TP	Micro Commercial Co, Zener Diode 36V 500mW ±5% Surface Mount SOD-123,	View
MMSZ5258B-TP	Micro Commercial Co, Zener Diode 36V 500mW ±5% Surface Mount SOD-123,	View
MMSZ4694-TP	Micro Commercial Co, Zener Diode 8.2V 500mW ±5% Surface Mount SOD-123,	View
MMSZ5262B-TP	Micro Commercial Co, Zener Diode 51V 500mW ±5% Surface Mount SOD-123,	View
MMSZ4679-TP	Micro Commercial Co, Zener Diode 2V 500mW ±5% Surface Mount SOD-123,	View
MMSZ4709-TP	Micro Commercial Co, Zener Diode 24V 500mW ±5% Surface Mount SOD-123,	View
MMSZ5230B-TP	Micro Commercial Co, Zener Diode 4.7V 500mW ±5% Surface Mount SOD-123,	View
MMSZ4713-TP	Micro Commercial Co, Zener Diode 30V 500mW ±5% Surface Mount SOD-123,	View
MMSZ4688-TP	Micro Commercial Co, Zener Diode 4.7V 500mW ±5% Surface Mount SOD-123,	View
MMSZ4696-TP	Micro Commercial Co, Zener Diode 9.1V 500mW ±5% Surface Mount SOD-123,	View

MMSZ5242B-TP

Part NumberMMSZ5242B-TP
