MPX1D0520LR15
MPX1D0520LR15
Part Number MPX1D0520LR15 Manufacturer KEMET Description INDUCTOR METAL 0.15 UH, 22A, 3.9 Package / Case NonstandardUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 150nH Shielded Inductor 16.9A 3.9mOhm Max Nonstandard
To learn about the specification of MPX1D0520LR15, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add MPX1D0520LR15 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of MPX1D0520LR15.
We are offering MPX1D0520LR15 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
MPX1D0520LR15 - Product Attributes
Categories
Inductors, Coils, Chokes / Fixed Inductors
Datasheet MPX Series Standard Package 1 Manufacturer KEMET Series MPX Packaging Cut Tape (CT) Part Status Active Type - Material - Core Metal Composite Inductance 150nH Tolerance ±20% Current Rating (Amps) 16.9A Current - Saturation 22A Shielding Shielded DC Resistance (DCR) 3.9mOhm Max Q @ Freq - Frequency - Self Resonant - Ratings - Operating Temperature -55°C ~ 155°C Inductance Frequency - Test 100kHz Features - Mounting Type Surface Mount Package / Case Nonstandard Supplier Device Package - Size / Dimension 0.209" L x 0.197" W (5.30mm x 5.00mm) Height - Seated (Max) 0.079" (2.00mm)
