Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	MPX Series
Standard Package	1
Manufacturer	KEMET
Series	MPX
Packaging	Cut Tape (CT)
Part Status	Active
Type	-
Material - Core	Metal Composite
Inductance	33µH
Tolerance	±20%
Current Rating (Amps)	2.8A
Current - Saturation	4A
Shielding	Shielded
DC Resistance (DCR)	229.5mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-55°C ~ 155°C
Inductance Frequency - Test	100kHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.341" L x 0.315" W (8.65mm x 8.00mm)
Height - Seated (Max)	0.118" (3.00mm)

MPX1D0830L3R3	KEMET, 3.3µH Shielded Inductor 8.9A 22.3mOhm Max Nonstandard, MPX	View
MPX1D0630LR47	KEMET, 470nH Shielded Inductor 18.7A 4mOhm Max Nonstandard, MPX	View
MPX1D0530L150	KEMET, 15µH Shielded Inductor 2.5A 214.6mOhm Max Nonstandard, MPX	View
MPX156K305N	Illinois Capacitor, 15µF Film Capacitor 305V Polypropylene (PP), Metallized Radial, MPX	View
MPX1D0830L330	KEMET, 33µH Shielded Inductor 2.8A 229.5mOhm Max Nonstandard, MPX	View
MPX1D0830L100	KEMET, 10µH Shielded Inductor 5.4A 61.7mOhm Max Nonstandard, MPX	View
MPX1D0618L4R7	KEMET, 4.7µH Shielded Inductor 3.4A 83.4mOhm Max Nonstandard, MPX	View
MPX1D0650L4R7	KEMET, 4.7µH Shielded Inductor 6.7A 32mOhm Max Nonstandard, MPX	View
MPX1D0520LR22	KEMET, 220nH Shielded Inductor 15A 5mOhm Max Nonstandard, MPX	View
MPX1D0520LR47	KEMET, 470nH Shielded Inductor 12A 7.8mOhm Max Nonstandard, MPX	View
MPX1D0530L1R5	KEMET, 1.5µH Shielded Inductor 8.6A 17.7mOhm Max Nonstandard, MPX	View
MPX1D0630LR68	KEMET, 680nH Shielded Inductor 15.1A 6.2mOhm Max Nonstandard, MPX	View

MPX1D0830L330

Part NumberMPX1D0830L330
