Categories	Filters / Ferrite Beads and Chips
Datasheet	MPZ0603 Series, Commercial Datasheet
Standard Package	15000
Manufacturer	TDK Corporation
Series	MPZ
Packaging	Tape & Reel (TR)
Part Status	Active
Filter Type	Power Line
Number of Lines	1
Impedance @ Frequency	47 Ohms @ 100MHz
Current Rating (Max)	500mA
DC Resistance (DCR) (Max)	120mOhm
Ratings	-
Operating Temperature	-55°C ~ 125°C
Package / Case	0201 (0603 Metric)
Mounting Type	Surface Mount
Height (Max)	0.013" (0.33mm)
Size / Dimension	0.024" L x 0.012" W (0.60mm x 0.30mm)
