Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - RF
Datasheet	MRF101AN, MRF101BN Datasheet~Preliminary
Standard Package	250
Manufacturer	NXP USA Inc.
Series	-
Part Status	Active
Transistor Type	LDMOS
Frequency	1.8MHz ~ 250MHz
Gain	21.1dB
Voltage - Test	50V
Current Rating (Amps)	10µA
Noise Figure	-
Current - Test	100mA
Power - Output	115W
Voltage - Rated	133V
Package / Case	TO-220-3
Supplier Device Package	TO-220-3
