Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PCG Series
Standard Package	1
Manufacturer	Nichicon
Series	PCG
Packaging	Cut Tape (CT)
Part Status	Active
Type	Polymer
Capacitance	470µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	20mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	3.7A @ 100kHz
Lead Spacing	-
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.394" (10.00mm)
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD

PCG1C101MCL1GS	Nichicon, 100µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 30mOhm 2000 Hrs @ 105°C, PCG	View
PCG0E331MCL1GS	Nichicon, 330µF 2.5V Aluminum Polymer Capacitor Radial, Can - SMD 30mOhm 2000 Hrs @ 105°C, PCG	View
PCG1C821MCL1GS	Nichicon, 820µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 18mOhm 2000 Hrs @ 105°C, PCG	View
PCG1A102MCL1GS	Nichicon, 1000µF 10V Aluminum Polymer Capacitor Radial, Can - SMD 13mOhm 2000 Hrs @ 105°C, PCG	View
PCG0E331MCO1GS	Nichicon, 330µF 2.5V Aluminum Polymer Capacitor Radial, Can - SMD 10mOhm 2000 Hrs @ 105°C, PCG	View
PCG1C821MCL1GS	Nichicon, 820µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 18mOhm 2000 Hrs @ 105°C, PCG	View
PCG1A561MCL1GS	Nichicon, 560µF 10V Aluminum Polymer Capacitor Radial, Can - SMD 20mOhm 2000 Hrs @ 105°C, PCG	View
PCG1A821MCL1GS	Nichicon, 820µF 10V Aluminum Polymer Capacitor Radial, Can - SMD 15mOhm 2000 Hrs @ 105°C, PCG	View
PCG0J151MCL1GS	Nichicon, 150µF 6.3V Aluminum Polymer Capacitor Radial, Can - SMD 33mOhm 2000 Hrs @ 105°C, PCG	View
PCG0J222MCL1GS	Nichicon, 2200µF 6.3V Aluminum Polymer Capacitor Radial, Can - SMD 12mOhm 2000 Hrs @ 105°C, PCG	View
PCG1C271MCL1GS	Nichicon, 270µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 25mOhm 2000 Hrs @ 105°C, PCG	View
PCG0J471MCL1GS	Nichicon, 470µF 6.3V Aluminum Polymer Capacitor Radial, Can - SMD 22mOhm 2000 Hrs @ 105°C, PCG	View

PCG1C471MCL1GS

Part NumberPCG1C471MCL1GS
