Categories	Resistors / Through Hole Resistors
Datasheet	PNP Series
Standard Package	1000
Manufacturer	Yageo
Series	PNPV
Packaging	Tape & Box (TB)
Part Status	Active
Resistance	22 Ohms
Tolerance	±1%
Power (Watts)	1W
Composition	Wirewound
Features	Flame Retardant Coating, Safety
Temperature Coefficient	±300ppm/°C
Operating Temperature	-40°C ~ 200°C
Package / Case	Axial
Supplier Device Package	Axial
Size / Dimension	0.169" Dia x 0.394" L (4.30mm x 10.00mm)
Height - Seated (Max)	-
Number of Terminations	2
Failure Rate	-

PNP3WVJR-73-0R3	Yageo, 300 mOhms ±5% 3W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP5WVJT-73-12R	Yageo, 12 Ohms ±5% 5W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP7WVJT-91-3K9	Yageo, 3.9 kOhms ±5% 7W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP5WVJT-73-2K7	Yageo, 2.7 kOhms ±5% 5W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP3WVJR-73-0R1	Yageo, 100 mOhms ±5% 3W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP3WVJR-73-0R3	Yageo, 300 mOhms ±5% 3W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP3WVJR-73-4R7	Yageo, 4.7 Ohms ±5% 3W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP3WVJR-73-220R	Yageo, 220 Ohms ±5% 3W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP5WVJT-73-0R33	Yageo, 330 mOhms ±5% 5W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP5WVJT-73-1K	Yageo, 1 kOhms ±5% 5W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP7WVFT-91-2R	Yageo, 2 Ohms ±1% 7W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View
PNP1WVJR-52-6R8	Yageo, 6.8 Ohms ±5% 1W Through Hole Resistor Axial Flame Retardant Coating, Safety Wirewound, PNPV	View

PNP1WVFTF52-22R

Part NumberPNP1WVFTF52-22R
