PSMN025-80YLX

PSMN025-80YLX

Part NumberPSMN025-80YLX

ManufacturerNexperia USA Inc.

DescriptionMOSFET N-CH 80V LFPAK56

DatasheetPSMN025-80YL

Package / CaseSC-100, SOT-669

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 80V 37A (Tc) 95W (Tc) Surface Mount LFPAK56, Power-SO8

To learn about the specification of PSMN025-80YLX, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add PSMN025-80YLX with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of PSMN025-80YLX.
We are offering PSMN025-80YLX for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

PSMN025-80YLX - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	PSMN025-80YL
Standard Package	1
Manufacturer	Nexperia USA Inc.
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	80V
Current - Continuous Drain (Id) @ 25°C	37A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	5V, 10V
Rds On (Max) @ Id, Vgs	25mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	2.1V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	17.1nC @ 5V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	2703pF @ 25V
FET Feature	-
Power Dissipation (Max)	95W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	LFPAK56, Power-SO8
Package / Case	SC-100, SOT-669
