Categories	Capacitors / Film Capacitors
Datasheet	R76 Series
Standard Package	1750
Manufacturer	KEMET
Series	R76
Packaging	Bulk
Part Status	Active
Capacitance	0.022µF
Tolerance	±5%
Voltage Rating - AC	600V
Voltage Rating - DC	1000V (1kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 110°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.709" L x 0.236" W (18.00mm x 6.00mm)
Height - Seated (Max)	0.476" (12.10mm)
Termination	PC Pins
Lead Spacing	0.591" (15.00mm)
Applications	Automotive; High Frequency, Switching; High Pulse, DV/DT
Ratings	AEC-Q200
Features	-

R76TR33304030J	KEMET, 0.33µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76MN3470SE30J	KEMET, 0.47µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial, R76	View
R76QW41004030J	KEMET, 1µF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial, R76	View
R76MI24704030J	KEMET, 0.047µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial, R76	View
R76UR32204030J	KEMET, 0.22µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial, R76	View
R76MN32204030J	KEMET, 0.22µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial, R76	View
R76TR3330SE30J	KEMET, 0.33µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76QD0470SE00K	KEMET, 470pF Film Capacitor 400V 1000V (1kV) Polypropylene (PP), Metallized Radial, R76	View
R76PD1100SE00J	KEMET, 1000pF Film Capacitor 250V 630V Polypropylene (PP), Metallized Radial, R76	View
R76TR31004030J	KEMET, 0.1µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76TR34704030J	KEMET, 0.47µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76UN23304040J	KEMET, 0.033µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial, R76	View

R76QI2220JE40J

Part NumberR76QI2220JE40J
