Categories	Potentiometers, Variable Resistors / Rotary Potentiometers, Rheostats
Datasheet	Rheostats
Standard Package	1
Manufacturer	Ohmite
Series	E
Packaging	Bulk
Part Status	Active
Resistance (Ohms)	75
Tolerance	±10%
Power (Watts)	12.5W
Built in Switch	None
Number of Turns	1
Taper	Linear
Number of Gangs	1
Adjustment Type	User Defined
Temperature Coefficient	-
Rotation	300°
Resistive Material	Wirewound
Termination Style	Solder Lug
Actuator Type	Slotted
Actuator Length	0.625" (15.88mm)
Actuator Diameter	0.125" (3.18mm)
Bushing Thread	1/4-32
Mounting Type	Panel Mount
Size - Body	-
