Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	RL8 Series
Standard Package	1000
Manufacturer	Nichicon
Series	FPCAP, RL8
Packaging	Tape & Box (TB)
Part Status	Active
Type	Polymer
Capacitance	330µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	12mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	500mA @ 120Hz
Ripple Current @ High Frequency	5A @ 100kHz
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.354" (9.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

RL81C101MDN1KX	Nichicon, 100µF 16V Aluminum Polymer Capacitor Radial, Can 12mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL81C181MDN1KX	Nichicon, 180µF 16V Aluminum Polymer Capacitor Radial, Can 12mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL80J821MDN1KX	Nichicon, 820µF 6.3V Aluminum Polymer Capacitor Radial, Can 8mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL81C181MDN1	Nichicon, 180µF 16V Aluminum Polymer Capacitor Radial, Can 12mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL81C181MDN1KX	Nichicon, 180µF 16V Aluminum Polymer Capacitor Radial, Can 12mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL80J471MDNASQKX	Nichicon, 470µF 6.3V Aluminum Polymer Capacitor Radial, Can 8mOhm 5000 Hrs @ 105°C, FPCAP, RL8	View
RL80E821MDNASQKX	Nichicon, 820µF 2.5V Aluminum Polymer Capacitor Radial, Can 6mOhm 5000 Hrs @ 105°C, FPCAP, RL8	View
RL80J561MDN1KX	Nichicon, 560µF 6.3V Aluminum Polymer Capacitor Radial, Can 8mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL80J821MDN1KX	Nichicon, 820µF 6.3V Aluminum Polymer Capacitor Radial, Can 8mOhm 2000 Hrs @ 105°C, FPCAP, RL8	View
RL80J561MDNASQKX	Nichicon, 560µF 6.3V Aluminum Polymer Capacitor Radial, Can 8mOhm 5000 Hrs @ 105°C, FPCAP, RL8	View
RL80E821MDNASQKX	Nichicon, 820µF 2.5V Aluminum Polymer Capacitor Radial, Can 6mOhm 5000 Hrs @ 105°C, FPCAP, RL8	View
RL80J471MDNASQKX	Nichicon, 470µF 6.3V Aluminum Polymer Capacitor Radial, Can 8mOhm 5000 Hrs @ 105°C, FPCAP, RL8	View

RL81C331MDN1KX

Part NumberRL81C331MDN1KX
