RLB0913-100K


RLB0913-100K

Part NumberRLB0913-100K

Manufacturer

Description

Datasheet

Package / CaseRadial, Vertical Cylinder

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

RLB0913-100K - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package200
ManufacturerBourns Inc.
SeriesRLB0913
PackagingTray
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance10µH
Tolerance±10%
Current Rating (Amps)3.1A
Current - Saturation3A
ShieldingUnshielded
DC Resistance (DCR)45mOhm
Q @ Freq50 @ 2.52MHz
Frequency - Self Resonant14MHz
Ratings-
Operating Temperature-55°C ~ 125°C
Inductance Frequency - Test1kHz
Mounting TypeThrough Hole
Package / CaseRadial, Vertical Cylinder
Supplier Device Package-
Size / Dimension0.335" Dia (8.50mm)
Height - Seated (Max)0.492" (12.50mm)
Base Part NumberRLB0913
