RN232-2.5-02-5M6
RN232-2.5-02-5M6
Part Number RN232-2.5-02-5M6 Description CMC 5.6MH 2.5A 2LN TH Package / Case Vertical, 4 PC PinUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 5.6mH @ 10kHz 2 Line Common Mode Choke Through Hole 2.5A DCR 86mOhm (Typ)
To learn about the specification of RN232-2.5-02-5M6, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add RN232-2.5-02-5M6 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of RN232-2.5-02-5M6.
We are offering RN232-2.5-02-5M6 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
RN232-2.5-02-5M6 - Product Attributes
Categories
Filters / Common Mode Chokes
Datasheet RN Series Datasheet Standard Package 300 Manufacturer Schaffner EMC Inc. Series RN Packaging Tray Part Status Active Filter Type Power Line Number of Lines 2 Inductance @ Frequency 5.6mH @ 10kHz Current Rating (Max) 2.5A DC Resistance (DCR) (Max) 86mOhm (Typ) Voltage Rating - DC - Voltage Rating - AC 300V Operating Temperature -40°C ~ 100°C Ratings - Approvals ENEC, UR, VDE Features - Mounting Type Through Hole Size / Dimension 1.220" L x 0.709" W (31.00mm x 18.00mm) Height (Max) 1.362" (34.60mm) Package / Case Vertical, 4 PC Pin
