Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	RNU Series Datasheet
Standard Package	1
Manufacturer	Nichicon
Series	FPCAP, RNU
Packaging	Cut Tape (CT)
Part Status	Active
Type	Polymer
Capacitance	150µF
Tolerance	±20%
Voltage - Rated	35V
ESR (Equivalent Series Resistance)	20mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	380mA @ 120Hz
Ripple Current @ High Frequency	3.8A @ 100kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.551" (14.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

RNU1E221MDNASQ	Nichicon, 220µF 25V Aluminum Polymer Capacitor Radial, Can 16mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0J152MDN1	Nichicon, 1500µF 6.3V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1C471MDN1PH	Nichicon, 470µF 16V Aluminum Polymer Capacitor Radial, Can 10mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E391MDNASQ	Nichicon, 390µF 25V Aluminum Polymer Capacitor Radial, Can 14mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E181MDN1KX	Nichicon, 180µF 25V Aluminum Polymer Capacitor Radial, Can 16mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E330MDN1KX	Nichicon, 33µF 25V Aluminum Polymer Capacitor Radial, Can 24mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0G222MDN1PH	Nichicon, 2200µF 4V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0G102MDN1KX	Nichicon, 1000µF 4V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E331MDN1PH	Nichicon, 330µF 25V Aluminum Polymer Capacitor Radial, Can 14mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1C681MDN1PH	Nichicon, 680µF 16V Aluminum Polymer Capacitor Radial, Can 10mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1J330MDN1KX	Nichicon, 33µF 63V Aluminum Polymer Capacitor Radial, Can 26mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1C271MDNASQKX	Nichicon, 270µF 16V Aluminum Polymer Capacitor Radial, Can 8mOhm 5000 Hrs @ 105°C, FPCAP, RNU	View

RNU1V151MDN1PH

Part NumberRNU1V151MDN1PH
