RT8532-20-2M5

RT8532-20-2M5

Part NumberRT8532-20-2M5

ManufacturerSchaffner EMC Inc.

DescriptionCMC 2.5MH 20A 3LN TH

DatasheetRT Series Datasheet

Package / CaseVertical, 6 PC Pin

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description2.5mH @ 100kHz 3 Line Common Mode Choke Through Hole 20A DCR 7mOhm (Typ)

To learn about the specification of RT8532-20-2M5, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add RT8532-20-2M5 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of RT8532-20-2M5.
We are offering RT8532-20-2M5 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

RT8532-20-2M5 - Product Attributes

Categories	Filters / Common Mode Chokes
Datasheet	RT Series Datasheet
Standard Package	70
Manufacturer	Schaffner EMC Inc.
Series	RT
Part Status	Active
Filter Type	Power Line
Number of Lines	3
Inductance @ Frequency	2.5mH @ 100kHz
Current Rating (Max)	20A
DC Resistance (DCR) (Max)	7mOhm (Typ)
Voltage Rating - DC	-
Voltage Rating - AC	600V
Operating Temperature	-40°C ~ 100°C
Ratings	-
Approvals	-
Features	-
Mounting Type	Through Hole
Size / Dimension	2.205" L x 1.457" W (56.00mm x 37.00mm)
Height (Max)	2.362" (60.00mm)
Package / Case	Vertical, 6 PC Pin
