Categories	Resistors / Chip Resistor - Surface Mount
Datasheet	Surface Mount Power
Standard Package	100
Manufacturer	Ohmite
Series	RW
Packaging	Bulk
Part Status	Active
Resistance	20 mOhms
Tolerance	±5%
Power (Watts)	2W
Composition	Wirewound
Features	Current Sense
Temperature Coefficient	±90ppm/°C
Operating Temperature	-55°C ~ 150°C
Package / Case	4122 J-Lead
Supplier Device Package	SMD J-Lead, Pedestal
Size / Dimension	0.407" L x 0.226" W (10.34mm x 5.74mm)
Height - Seated (Max)	0.227" (5.77mm)
Number of Terminations	2
Failure Rate	-

RW3R5EA1R00JE	Ohmite, 1 Ohms ±5% 3.5W Chip Resistor 8127 J-Lead Current Sense Wirewound, RW	View
RW2S0CBR010JET	Ohmite, 10 mOhms ±5% 2W Chip Resistor 4122 J-Lead Current Sense Wirewound, RW	View
RW2S0DA24R0JE	Ohmite, 24 Ohms ±5% 2W Chip Resistor 4524 J-Lead Current Sense Wirewound, RW	View
RW3R0DB5R00JE	Ohmite, 5 Ohms ±5% 3W Chip Resistor 6327 J-Lead Current Sense Wirewound, RW	View
RW2S0CBR200JE	Ohmite, 200 mOhms ±5% 2W Chip Resistor 4122 J-Lead Current Sense Wirewound, RW	View
RW2S0DA68R0JE	Ohmite, 68 Ohms ±5% 2W Chip Resistor 4524 J-Lead Current Sense Wirewound, RW	View
RW0S6BBR100FET	Ohmite, 100 mOhms ±1% 0.6W Chip Resistor 2010 (5025 Metric) Current Sense Wirewound, RW	View
RW3R0DB1R00JET	Ohmite, 1 Ohms ±5% 3W Chip Resistor 6327 J-Lead Current Sense Wirewound, RW	View
RW3R5EAR100JE	Ohmite, 100 mOhms ±5% 3.5W Chip Resistor 8127 J-Lead Current Sense Wirewound, RW	View
RW2S0CBR020JE	Ohmite, 20 mOhms ±5% 2W Chip Resistor 4122 J-Lead Current Sense Wirewound, RW	View
RW1S0BAR050FE	Ohmite, 50 mOhms ±1% 1W Chip Resistor 2512 J-Lead Current Sense Wirewound, RW	View
RW3R5EAR010JE	Ohmite, 10 mOhms ±5% 3.5W Chip Resistor 8127 J-Lead Current Sense Wirewound, RW	View

RW2S0CBR020JE

Part NumberRW2S0CBR020JE
