Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	S10A-10M
Standard Package	1
Manufacturer	Micro Commercial Co
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	1000V
Current - Average Rectified (Io)	10A
Voltage - Forward (Vf) (Max) @ If	1.2V @ 10A
Speed	Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	10µA @ 1000V
Capacitance @ Vr, F	-
Mounting Type	Surface Mount
Package / Case	DO-214AB, SMC
Supplier Device Package	DO-214AB (HSMC)
Operating Temperature - Junction	-55°C ~ 150°C
Base Part Number	S10M
