SB240E-G

SB240E-G

Part NumberSB240E-G

ManufacturerComchip Technology

DescriptionDIODE SCHOTTKY 40V 2A DO15

DatasheetSB220E-2100E-G

Package / CaseDO-204AC, DO-15, Axial

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Schottky 40V 2A Through Hole DO-15

To learn about the specification of SB240E-G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SB240E-G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SB240E-G.
We are offering SB240E-G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SB240E-G - Product Attributes

Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	SB220E-2100E-G
Standard Package	1
Manufacturer	Comchip Technology
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	40V
Current - Average Rectified (Io)	2A
Voltage - Forward (Vf) (Max) @ If	500mV @ 2A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	500µA @ 40V
Capacitance @ Vr, F	170pF @ 4V, 1MHz
Mounting Type	Through Hole
Package / Case	DO-204AC, DO-15, Axial
Supplier Device Package	DO-15
Operating Temperature - Junction	-65°C ~ 125°C
Base Part Number	SB240
