Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	SBCP Series Datasheet
Standard Package	100
Manufacturer	KEMET
Series	SBCP
Packaging	Bulk
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	10mH
Tolerance	±10%
Current Rating (Amps)	100mA
Current - Saturation	150mA
Shielding	Unshielded
DC Resistance (DCR)	19.1Ohm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-20°C ~ 105°C
Inductance Frequency - Test	10kHz
Features	-
Mounting Type	Through Hole
Package / Case	Radial, Vertical Cylinder
Supplier Device Package	-
Size / Dimension	0.374" Dia (9.50mm)
Height - Seated (Max)	0.433" (11.00mm)

SBC7-681-701	KEMET, 680µH Unshielded Wirewound Inductor 700mA 810mOhm Max Radial, Vertical Cylinder, SBC	View
SBC3-332-151	KEMET, 3.3mH Unshielded Wirewound Inductor 150mA 7.66Ohm Max Radial, Vertical Cylinder, SBC	View
SBC7-222-421	KEMET, 2.2mH Unshielded Wirewound Inductor 420mA 2.18Ohm Max Radial, Vertical Cylinder, SBC	View
SBC6-681-631	KEMET, 680µH Unshielded Wirewound Inductor 630mA 980mOhm Max Radial, Vertical Cylinder, SBC	View
SBCP-14HY222B	KEMET, 2.2mH Unshielded Wirewound Inductor 380mA 2.36Ohm Max Radial, Vertical Cylinder (Open), SBCP	View
SBCP-47HY471B	KEMET, 470µH Unshielded Wirewound Inductor 220mA 2.8Ohm Max Radial, Vertical Cylinder (Open), SBCP	View
SBCP-47HY560B	KEMET, 56µH Unshielded Wirewound Inductor 650mA 350mOhm Max Radial, Vertical Cylinder (Open), SBCP	View
SBCP-80HY121H	KEMET, 120µH Unshielded Wirewound Inductor 1.1A 350mOhm Max Radial, Vertical Cylinder, SBCP	View
SBCP-11HY101H	KEMET, 100µH Unshielded Wirewound Inductor 1.3A 190mOhm Max Radial, Vertical Cylinder, SBCP	View
SBCP-87HY1R0H	KEMET, 1µH Unshielded Wirewound Inductor 4.5A 20mOhm Max Radial, Vertical Cylinder, SBCP	View
SBCP-47HY220B	KEMET, 22µH Unshielded Wirewound Inductor 1.05A 123mOhm Max Radial, Vertical Cylinder (Open), SBCP	View
SBCP-11HY100H	KEMET, 10µH Unshielded Wirewound Inductor 3.1A 40mOhm Max Radial, Vertical Cylinder, SBCP	View

SBCP-80HY103HB

Part NumberSBCP-80HY103HB
