Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	SCRH8D43 Series
Standard Package	1
Manufacturer	Signal Transformer
Series	SCRH8D43
Packaging	Cut Tape (CT)
Part Status	Active
Type	-
Material - Core	-
Inductance	68µH
Tolerance	±30%
Current Rating (Amps)	1.2A
Current - Saturation	1.2A
Shielding	Shielded
DC Resistance (DCR)	240mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.327" L x 0.327" W (8.30mm x 8.30mm)
Height - Seated (Max)	0.185" (4.70mm)

SCRH127-220	Signal Transformer, 22µH Shielded Inductor 4A 43.2mOhm Max Nonstandard, SCRH127	View
SCRH8D43-680	Signal Transformer, 68µH Shielded Inductor 1.2A 240mOhm Max Nonstandard, SCRH8D43	View
302R29W681KV3E-****-SC	Johanson Dielectrics Inc., 680pF ±10% 250V Ceramic Capacitor X7R 1808 (4520 Metric), SC	View
SCRH104R-150	Signal Transformer, 15µH Shielded Inductor 3.1A 50mOhm Max Nonstandard, SCRH104R	View
SCIHP1367-100M	Signal Transformer, 10µH Shielded Wirewound Inductor 10A 18.5mOhm Max Nonstandard, SCIHP1367	View
SC-02-300	KEMET, 3mH @ 100kHz 2 Line Common Mode Choke Through Hole 2A DCR 100mOhm, SC	View
SC-05-500	KEMET, 5mH @ 100kHz 2 Line Common Mode Choke Through Hole 4A DCR 80mOhm, SC	View
SCRH125-470	Signal Transformer, 47µH Shielded Inductor 2.48A 75mOhm Max Nonstandard, SCRH125	View
302R29N100KV3E-****-SC	Johanson Dielectrics Inc., 10pF ±10% 250V Ceramic Capacitor C0G, NP0 1808 (4520 Metric), SC	View
SC01001518	Skyworks Solutions Inc., 10pF Silicon Capacitor Nonstandard, SC	View
SCIHP0420TB-1R2	Signal Transformer, 1.2µH Shielded Wirewound Inductor 4.5A Nonstandard, SCIHP0420TB	View
SCIHP0750-2R2	Signal Transformer, 2.2µH Shielded Wirewound Inductor 11A 15mOhm Max Nonstandard, SCIHP0750	View

SCRH8D43-680
