Categories	Capacitors / Ceramic Capacitors
Datasheet	SQ Series, Ulta Low ESR MLC
Standard Package	500
Manufacturer	AVX Corporation
Series	SQ
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	0.5pF
Tolerance	±0.1pF
Voltage - Rated	250V
Temperature Coefficient	M
Operating Temperature	-55°C ~ 125°C
Features	High Q, Low Loss, Ultra Low ESR
Ratings	-
Applications	RF, Microwave, High Frequency
Mounting Type	Surface Mount, MLCC
Package / Case	0505 (1313 Metric)
Size / Dimension	0.055" L x 0.055" W (1.40mm x 1.40mm)
Height - Seated (Max)	-
Thickness (Max)	0.022" (0.57mm)
Lead Spacing	-
Lead Style	-

SQCB7M680JAJME	AVX Corporation, 68pF ±5% 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCSVA2R7BAT1A	AVX Corporation, 2.7pF ±0.1pF 250V Ceramic Capacitor A 0603 (1608 Metric), SQ	View
SQCB7M430JATME\500	AVX Corporation, 43pF ±5% 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCB7M270JAJME	AVX Corporation, 27pF ±5% 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCFVA100JATME	AVX Corporation, 10pF ±5% 250V Ceramic Capacitor A 0805 (2012 Metric), SQ	View
SQCB7M470JATME	AVX Corporation, 47pF ±5% 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCAVM4R7BATME/500	AVX Corporation, 4.7pF ±0.1pF 250V Ceramic Capacitor M 0505 (1313 Metric), SQ	View
SQCB7M1R0BAJME	AVX Corporation, 1pF ±0.1pF 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCB7M2R2BAJME	AVX Corporation, 2.2pF ±0.1pF 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCB7M390JAT1A	AVX Corporation, 39pF ±5% 500V Ceramic Capacitor M 1111 (2828 Metric), SQ	View
SQCSVA820JAT1A	AVX Corporation, 82pF ±5% 250V Ceramic Capacitor A 0603 (1608 Metric), SQ	View
SQCAVM270JATME/500	AVX Corporation, 27pF ±5% 250V Ceramic Capacitor M 0505 (1313 Metric), SQ	View

SQCAVM0R5BATME/500

Part NumberSQCAVM0R5BATME/500
