SSM6N815R,LF

SSM6N815R,LF

Part NumberSSM6N815R,LF

ManufacturerToshiba Semiconductor and Storage

DescriptionMOSFET 2N-CH 100V 2A 6TSOPF

DatasheetSSM6N815R

Package / Case6-SMD, Flat Leads

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 2 N-Channel (Dual) 100V 2A (Ta) 1.8W (Ta) Surface Mount 6-TSOP-F

To learn about the specification of SSM6N815R,LF, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SSM6N815R,LF with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SSM6N815R,LF.
We are offering SSM6N815R,LF for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SSM6N815R,LF - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet	SSM6N815R
Standard Package	1
Manufacturer	Toshiba Semiconductor and Storage
Series	U-MOSVIII-H
Packaging	Cut Tape (CT)
Part Status	Active
FET Type	2 N-Channel (Dual)
FET Feature	Logic Level Gate, 4V Drive
Drain to Source Voltage (Vdss)	100V
Current - Continuous Drain (Id) @ 25°C	2A (Ta)
Vgs(th) (Max) @ Id	2.5V @ 100µA
Gate Charge (Qg) (Max) @ Vgs	3.1nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds	290pF @ 15V
Power - Max	1.8W (Ta)
Operating Temperature	150°C
Mounting Type	Surface Mount
Package / Case	6-SMD, Flat Leads
Supplier Device Package	6-TSOP-F
