STF33N60DM2


STF33N60DM2

Part NumberSTF33N60DM2

Manufacturer

Description

Package / CaseTO-220-3 Full Pack

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

STF33N60DM2 - Product Attributes

Categories Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Standard Package50
ManufacturerSTMicroelectronics
SeriesMDmesh™ DM2
PackagingTube
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)650V
Current - Continuous Drain (Id) @ 25°C24A (Tc)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs130mOhm @ 12A, 10V
Vgs(th) (Max) @ Id5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs43nC @ 10V
Vgs (Max)±25V
Input Capacitance (Ciss) (Max) @ Vds1870pF @ 100V
FET Feature-
Power Dissipation (Max)35W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeThrough Hole
Supplier Device PackageTO-220FP
Package / CaseTO-220-3 Full Pack
