STL12P6F6

STL12P6F6

Part NumberSTL12P6F6

ManufacturerSTMicroelectronics

DescriptionMOSFET P-CH 60V 4A 8POWERFLAT

DatasheetSTL12P6F6

Package / Case8-PowerVDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionP-Channel 60V 4A (Tc) 75W (Tc) Surface Mount PowerFlat™ (5x6)

To learn about the specification of STL12P6F6, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add STL12P6F6 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of STL12P6F6.
We are offering STL12P6F6 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

STL12P6F6 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	STL12P6F6
Standard Package	1
Manufacturer	STMicroelectronics
Series	DeepGATE™, STripFET™ VI
Packaging	Cut Tape (CT)
Part Status	Active
FET Type	P-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	4A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	160mOhm @ 1.5A, 10V
Vgs(th) (Max) @ Id	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	6.4nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	340pF @ 48V
FET Feature	-
Power Dissipation (Max)	75W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PowerFlat™ (5x6)
Package / Case	8-PowerVDFN
