STPS1L20MF

STPS1L20MF

Part NumberSTPS1L20MF

ManufacturerSTMicroelectronics

DescriptionDIODE SCHOTTKY 20V 1A STMITEFLAT

DatasheetSTPS1L20MF

Package / CaseDO-222AA

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Schottky 20V 1A Surface Mount STmite Flat

To learn about the specification of STPS1L20MF, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add STPS1L20MF with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of STPS1L20MF.
We are offering STPS1L20MF for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

STPS1L20MF - Product Attributes

Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	STPS1L20MF
Standard Package	1
Manufacturer	STMicroelectronics
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	20V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	430mV @ 1A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	75µA @ 20V
Capacitance @ Vr, F	-
Mounting Type	Surface Mount
Package / Case	DO-222AA
Supplier Device Package	STmite Flat
Operating Temperature - Junction	150°C (Max)
Base Part Number	STPS1L20
