Home/Product Catalog/Filters / Common Mode Chokes/  SU16VD-40010

SU16VD-40010


SU16VD-40010

Part NumberSU16VD-40010

Manufacturer

Description

Datasheet

Package / CaseVertical, 4 PC Pin

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

SU16VD-40010 - Product Attributes

Categories Filters / Common Mode Chokes
Datasheet
Standard Package600
ManufacturerKEMET
SeriesSU
PackagingBulk
Part StatusActive
Filter TypePower Line
Number of Lines2
Inductance @ Frequency10µH @ 1kHz
Current Rating (Max)4A
DC Resistance (DCR) (Max)40mOhm
Voltage Rating - DC-
Voltage Rating - AC250V
Operating Temperature-25°C ~ 120°C
Ratings-
Approvals-
Features-
Mounting TypeThrough Hole
Size / Dimension0.906" L x 0.748" W (23.00mm x 19.00mm)
Height (Max)1.083" (27.50mm)
Package / CaseVertical, 4 PC Pin
