Categories	Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Datasheet	TBS20A thru TBS20M
Standard Package	1
Manufacturer	Micro Commercial Co
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Single Phase
Technology	Standard
Voltage - Peak Reverse (Max)	600V
Current - Average Rectified (Io)	2A
Voltage - Forward (Vf) (Max) @ If	1.1V @ 2A
Current - Reverse Leakage @ Vr	5µA @ 600V
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	4-SMD, Flat Leads
Supplier Device Package	4-TBS

CDBHM160L-HF	Comchip Technology, Bridge Rectifier Single Phase Schottky 60V Surface Mount MBS,	View
DBLS105G RDG	Taiwan Semiconductor Corporation, Bridge Rectifier Single Phase Standard 600V Surface Mount DBLS,	View
CDBHM160L-HF	Comchip Technology, Bridge Rectifier Single Phase Schottky 60V Surface Mount MBS,	View
KMB25STR	SMC Diode Solutions, Bridge Rectifier Single Phase Schottky 50V Surface Mount MBS,	View
Z4GP206L-HF	Comchip Technology, Bridge Rectifier Single Phase Standard 600V Surface Mount ABS(Z4),	View
T483A	Sensata-Crydom, Bridge Rectifier Single Phase Standard 200V Surface Mount Module,	View
MB10F-13	Diodes Incorporated, Bridge Rectifier Single Phase Standard 1kV Surface Mount MBF,	View
CBR1-D020S TR13	Central Semiconductor Corp, Bridge Rectifier Single Phase Standard 200V Surface Mount 4-SMDIP,	View
RMB2S RCG	Taiwan Semiconductor Corporation, Bridge Rectifier Single Phase Standard 200V Surface Mount MBS,	View
CBRHD-01 TR13	Central Semiconductor Corp, Bridge Rectifier Single Phase Standard 100V Surface Mount 4-HD DIP,	View
DBLS207G RDG	Taiwan Semiconductor Corporation, Bridge Rectifier Single Phase Standard 1kV Surface Mount DBLS,	View
HDS20M-13	Diodes Incorporated, Bridge Rectifier Single Phase Standard 1kV Surface Mount HDS,	View

TBS20J-TP

Part NumberTBS20J-TP
