TMC1320-LA

Part NumberTMC1320-LA

ManufacturerTrinamic Motion Control GmbH

DescriptionMOSFET N/P-CH 30V 8PQFN

DatasheetTMC1320-LA

Package / Case8-PowerTDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array N and P-Channel, Common Drain 30V 7.3A, 5.3A 2.5W Surface Mount 8-PQFN (3x3)

To learn about the specification of TMC1320-LA, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add TMC1320-LA with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of TMC1320-LA.
We are offering TMC1320-LA for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

TMC1320-LA - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays

Datasheet

TMC1320-LA

Standard Package

Manufacturer

Trinamic Motion Control GmbH

Series

Packaging

Cut Tape (CT)

Part Status

Obsolete

FET Type

N and P-Channel, Common Drain

FET Feature

Standard

Drain to Source Voltage (Vdss)

30V

Current - Continuous Drain (Id) @ 25°C

7.3A, 5.3A

Rds On (Max) @ Id, Vgs

30mOhm @ 4A, 10V

Vgs(th) (Max) @ Id

3V @ 250µA

Gate Charge (Qg) (Max) @ Vgs

7.2nC @ 4.5V

Input Capacitance (Ciss) (Max) @ Vds

400pF @ 25V

Power - Max

2.5W

Operating Temperature

-55°C ~ 150°C (TJ)

Mounting Type

Surface Mount

Package / Case

8-PowerTDFN

Supplier Device Package

8-PQFN (3x3)
