TMMBAT46FILM

TMMBAT46FILM

Part NumberTMMBAT46FILM

ManufacturerSTMicroelectronics

DescriptionDIODE SCHOTTKY 100V 150MA MINMLF

DatasheetTMMBAT46

Package / CaseDO-213AA (Glass)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Schottky 100V 150mA (DC) Surface Mount Mini MELF

To learn about the specification of TMMBAT46FILM, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add TMMBAT46FILM with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of TMMBAT46FILM.
We are offering TMMBAT46FILM for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

TMMBAT46FILM - Product Attributes

Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	TMMBAT46
Standard Package	1
Manufacturer	STMicroelectronics
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	100V
Current - Average Rectified (Io)	150mA (DC)
Voltage - Forward (Vf) (Max) @ If	450mV @ 10mA
Speed	Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr	5µA @ 75V
Capacitance @ Vr, F	10pF @ 0V, 1MHz
Mounting Type	Surface Mount
Package / Case	DO-213AA (Glass)
Supplier Device Package	Mini MELF
Operating Temperature - Junction	-65°C ~ 125°C
Base Part Number	BAT46
