TSM250N02DCQ RFG

Part NumberTSM250N02DCQ RFG

ManufacturerTaiwan Semiconductor Corporation

DescriptionMOSFET 2 N-CH 20V 5.8A 6TDFN

DatasheetTSM250N02D

Package / Case6-VDFN Exposed Pad

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 2 N-Channel (Dual) 20V 5.8A (Tc) 620mW Surface Mount 6-TDFN (2x2)

To learn about the specification of TSM250N02DCQ RFG, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add TSM250N02DCQ RFG with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of TSM250N02DCQ RFG.
We are offering TSM250N02DCQ RFG for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

TSM250N02DCQ RFG - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet	TSM250N02D
Standard Package	1
Manufacturer	Taiwan Semiconductor Corporation
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
FET Type	2 N-Channel (Dual)
FET Feature	Standard
Drain to Source Voltage (Vdss)	20V
Current - Continuous Drain (Id) @ 25°C	5.8A (Tc)
Rds On (Max) @ Id, Vgs	25mOhm @ 4A, 4.5V
Vgs(th) (Max) @ Id	800mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs	7.7nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds	775pF @ 10V
Power - Max	620mW
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	6-VDFN Exposed Pad
Supplier Device Package	6-TDFN (2x2)
