TSS42U RGG


TSS42U RGG

Part NumberTSS42U RGG

Manufacturer

Description

Datasheet

Package / Case0201 (0603 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

TSS42U RGG - Product Attributes

Categories Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet
Standard Package1
ManufacturerTaiwan Semiconductor Corporation
Series-
PackagingCut Tape (CT)
Part StatusActive
Diode TypeSchottky
Voltage - DC Reverse (Vr) (Max)30V
Current - Average Rectified (Io)200mA
Voltage - Forward (Vf) (Max) @ If1V @ 200mA
SpeedSmall Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr500nA @ 25V
Capacitance @ Vr, F10pF @ 1V, 1MHz
Mounting TypeSurface Mount
Package / Case0201 (0603 Metric)
Supplier Device Package0603
Operating Temperature - Junction-55°C ~ 125°C
