Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UBT Series
Standard Package	50
Manufacturer	Nichicon
Series	UBT
Packaging	Bulk
Part Status	Active
Capacitance	2200µF
Tolerance	±20%
Voltage - Rated	35V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	10000 Hrs @ 125°C
Operating Temperature	-40°C ~ 125°C
Polarization	Polar
Ratings	-
Applications	Automotive
Ripple Current @ Low Frequency	1.869A @ 120Hz
Ripple Current @ High Frequency	2.79A @ 100kHz
Impedance	25 mOhms
Lead Spacing	0.295" (7.50mm)
Size / Dimension	0.709" Dia (18.00mm)
Height - Seated (Max)	1.476" (37.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UBT1C222MHD1TN	Nichicon, 2200µF 16V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 125°C, UBT	View
UBT2V4R7MPD1TD	Nichicon, 4.7µF 350V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 125°C, UBT	View
UBT2W220MHD1TN	Nichicon, 22µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 125°C, UBT	View
UBT2C470MHD1TO	Nichicon, 47µF 160V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 125°C, UBT	View
UBT1A222MHD1TO	Nichicon, 2200µF 10V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 125°C, UBT	View
UBT1C471MPD1TD	Nichicon, 470µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 125°C, UBT	View
UBT1C332MHD	Nichicon, 3300µF 16V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 125°C, UBT	View
UBT2V4R7MPD1TD	Nichicon, 4.7µF 350V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 125°C, UBT	View
UBT1H101MPD	Nichicon, 100µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 125°C, UBT	View
UBT1H471MHD8	Nichicon, 470µF 50V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 125°C, UBT	View
UBT1H4R7MPD1TD	Nichicon, 4.7µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 125°C, UBT	View
UBT2W4R7MPD1TD	Nichicon, 4.7µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 125°C, UBT	View

UBT1V222MHD

Part NumberUBT1V222MHD
