Home/Product Catalog/Capacitors / Aluminum Electrolytic Capacitors/ UCX1H470MCL1GS

UCX1H470MCL1GS

UCX1H470MCL1GS

Part NumberUCX1H470MCL1GS

ManufacturerNichicon

DescriptionCAP ALUM 47UF 20% 50V SMD

DatasheetUCX Series

Package / CaseRadial, Can - SMD

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description47µF 50V Aluminum Electrolytic Capacitors Radial, Can - SMD 250mOhm 2000 Hrs @ 135°C

To learn about the specification of UCX1H470MCL1GS, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add UCX1H470MCL1GS with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of UCX1H470MCL1GS.
We are offering UCX1H470MCL1GS for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

UCX1H470MCL1GS - Product Attributes

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UCX Series
Standard Package	500
Manufacturer	Nichicon
Series	UCX
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	47µF
Tolerance	±20%
Voltage - Rated	50V
ESR (Equivalent Series Resistance)	250mOhm
Lifetime @ Temp.	2000 Hrs @ 135°C
Operating Temperature	-40°C ~ 135°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	135mA @ 120Hz
Ripple Current @ High Frequency	270mA @ 100kHz
Lead Spacing	-
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.433" (11.00mm)
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD
